PET Reciprocating Air Compressors
Ingersoll Rand PETStar® 4 reciprocating air compressors are designed to deliver exceptional durability, reliability, and energy efficiency for PET applications. While conventional PET reciprocating compressors typically use three-stage compression, the PETStar® 4 utilizes an advanced four-stage compression system to achieve improved efficiency and optimized energy consumption.
Built with industrial-grade components and double-acting cast iron cylinders, PETStar® 4 compressors are engineered for long-term, dependable performance. Their robust construction helps reduce maintenance requirements, minimize operating costs, and lower overall lifecycle expenses.
Key Features
- Three-step capacity control (0%–50%–100%) helps match compressor output with changing air demand, optimizing energy consumption.
- Advanced Xe-Series compressor controller continuously monitors critical operating parameters to support efficient and reliable compressor performance.
- IP55 TEFC motor with star-delta starter provides energy-efficient motor starting and reliable operation.
- 100% oil-free, non-lubricated, water-cooled design delivers clean compressed air for demanding PET applications.
- Four-stage balanced, opposed configuration helps minimize vibration and ensures smooth, stable operation.
- Double-acting pistons with heavy-duty Class 40 cast iron cylinders provide excellent durability and extended service life.
- Piston rings and packing rated for up to 16,000 hours help extend maintenance intervals and reduce operating costs.
- Optional protective features, including rod-drop position wear indicators, provide additional monitoring and help identify potential component wear.
Specifications
| Model Name | Flow (m3hr / cfm) | Height (cm / in) | Width (cm / in) | Length (cm / in) | Rated Pressure (barg / psig) | Nominal Power (kW / hp) | Weight (kg / lbs) |
|---|---|---|---|---|---|---|---|
| PS4-1500 | 1,560 / 918 | 2.9 / 115 | 02.06.1990 | 6.7 / 270 | 40 / 580 | 242 / 350 | 21,500 / 47,700 |
| PS4-1700 | 1,762 / 1,037 | 2.9 / 115 | 02.06.1990 | 6.7 / 270 | 40 / 580 | 262 / 350 | 21,800 / 48,000 |
| PS4-1900 | 1,964 / 1,156 | 2.9 / 115 | 02.06.1990 | 6.7 / 270 | 40 / 580 | 298 / 400 | 22,000 / 48,300 |
| PS4-2100 | 2,187 / 1,287 | 2.9 / 115 | 02.06.1990 | 6.7 / 270 | 40 / 580 | 336 / 450 | 22,200 / 48,700 |
| PS4-2300 | 2,046 / 1,416 | 3.0 / 119 | 2.7 / 107 | 6.7 / 270 | 40 / 580 | 373 / 500 | 22,650 / 49,600 |
| PS4-2500 | 2,607 / 1,534 | 3.0 / 119 | 2.7 / 107 | 6.7 / 270 | 40 / 580 | 361 / 525 | 23,000 / 50,700 |
| PS4-2800 | 2,911 / 1,713 | 3.0 / 119 | 2.7 / 107 | 6.7 / 270 | 40 / 580 | 447 / 600 | 23,200 / 51,000 |
| PS4-3000 | 3,111 / 1,831 | 3.0 / 119 | 2.7 / 107 | 6.7 / 270 | 40 / 580 | 485 / 650 | 23,300 / 51,300 |
| PS4-3300 | 3,438 / 2,023 | 3.0 / 119 | 2.7 / 107 | 6.7 / 270 | 40 / 580 | 525 / 725 | 23,900 / 52,500 |
